- CONTINUOUS DUTY: 25 Amps
- ICS: 35 Amps
- POWER TERMINALS: 1/4"-20 Screw Type and Anderson Power Poles
- FAN COOLED: No
- Separate Voltage and Amperage Meters Included
Features and Specifications
- SOLID STATE ELECTRONICALLY REGULATED
- FOLD BACK CURRENT LIMITING Protects Power Supply from excessive current and continuous shorted output
- CROWBAR OVER VOLTAGE PROTECTION ON ALL MODELS
- MAINTAIN REGULATION AND LOW RIPPLE at low line input Voltage
- THREE CONDUCTOR POWER CORD
- HEAVY DUTY HEAT SINK
- INPUT VOLTAGE: 105-125VAC
- OUTPUT VOLTAGE: 13.8VDC ±0.05 volts
- INTERNALLY ADJUSTABLE VOLTAGE (11-15VDC)
- RIPPLE: LESS THAN 5MV PEAK TO PEAK (full load and low line)
- LOAD REGULATION: 0.08% from 0 to Full Continuous Load
- EFFICIENCY: 77%
- OPERATING TEMP: -10 to 55°C
- Product Dimensions : 11 x 11 x 5 inches; 27 Pounds
- Date First Available : December 12, 2019
- Manufacturer : Astron
- Country of Origin : USA
